Brake Drum 43206-01D20 Specifications
| Product Name | Brake Drum |
|---|---|
| OEM Number | 43206-01D20 / 4320601D20 |
| Cross Reference | ZF DB7268 |
| Application | Nissan UD trucks / Nissan Civilian bus |
| Position | Rear axle |
| Drum Diameter | 320 mm |
| Center Hole (Pilot Diameter) | 140 mm |
| Bolt Hole Circle (PCD) | 180 mm |
| Bolt Pattern | 6-hole |
| Total Height | 126.2 mm |
| Max Reboring Limit | 321.5 mm |
| Material | Gray cast iron |
| Place of Origin | Hebei, China |
Compatible Vehicle Applications
The 43206-01D20 brake drum is used on the following vehicles:
- Nissan UD (YU41T5 / TT42): Rear axle, 6-hole wheel bolt pattern, 3.5″ brake width
- Nissan Civilian (W41 bus): Rear brake drum, commercial passenger minibus
Product Description
This drum is cast from gray iron. It has a 320 mm drum diameter, a 140 mm center pilot hole, and a 6-bolt pattern on a 180 mm PCD. The total height is 126.2 mm, and the drum can be rebored up to 321.5 mm if needed.
The 43206-01D20 is also listed under ZF Aftermarket part number DB7268, so it can be sourced through ZF’s distribution network. The friction surface is machined to the correct diameter and finish for even contact with the brake linings.
About YIWO Brake Drums
YIWO supplies the 43206-01D20 brake drum from our facility in Hebei, China. We serve both domestic and export markets with a focus on commercial vehicle brake components. Contact us for pricing, stock availability, and custom branding options on bulk orders.
